HC Series Hydrocyclone
Uses:
-The continuous separation, concentration and washing of the starch and the modified starch made from potato, tapioca, sweet potato, wheat and other grain (rice).
-The clarification and washing of the suspension in other food and chemical industry.
Design Features:
-The shell and tube of the whole hydrocyclone are made of 304 stainless steel, and the cone is made of the wear-resistant engineering plastic.
-The seal of the entire system only uses 3 O-shaped rings. The quick-open doors connected with the hinges and the quick-replacement flow tube plate could work out by the front door shutting.
-The hygienic-class pipeline valve and system running in totally enclosed. The CIP can be cleaned conveniently and makes the bacteria rarely grow.
-With few manual operation and stable working pressure, the machine could be centralized controlled by PID or PLC system.
-The whole machine running with the light vibration and low noise and the highly efficient and continuous separation, which is stable and little water consumption.
Performance Parameters:
| Models |
Working Pressure |
Flow Range |
Installed Power |
Processing Capacity |
Net Weight(kg) |
| HC300/15 |
4.5-8.5 |
15-20 |
145 |
1.0-2.0 |
3200 |
| HC400/15 |
4.5-8.5 |
25-30 |
225 |
2.5-3.0 |
4000 |
| HC450/15 |
4.5-8.5 |
35-40 |
290 |
3.0-5.0 |
4600 |
| HC500/15 |
4.5-8.5 |
45-50 |
330 |
4.0-6.0 |
5550 |
| HC550/15 |
4.5-8.5 |
55-60 |
350 |
6.0-8.0 |
6500 |
| HC600/15 |
4.5-8.5 |
60-65 |
390 |
8.0-10 |
8000 |
